COFDM Wireless Video Camera Transmitter And Receiver 433mhz 800mhz

Name: COFDM Wireless Video Camera Transmitter And Receiver 433mhz 800mhz
Brand: Ding Shen
Price: 1 USD

Best COFDM Wireless Video Camera Transmitter And Receiver 433mhz 800mhz wholesale

Brand Name : Ding Shen

Model Number : DS-HDR30

Place of Origin : China

MOQ : 1set

Price : Negotiation

Payment Terms : T/T

Supply Ability : 1000pcs per month

Delivery Time : 3-7 days

Packaging Details : export packing standard

Certification : CE/FCC

DC Input : ≤1.1A DC12.5V

Modulation : COFDM

Constellation : QPSK,16QAM,64QAM (optional)

Carrier : 2K

Dimension : 170*140*60mm

Frequency input range : 300MHz~4700MHz

RF bandwidth : 4/8MHz (adjustable)

Contact Now

Product Features:
1.Small size and light weight;
2.Easy to be carried;
3.Safe and reliable;
4.Stereo audio output;
5.<-105dBm Sensitivity:
6.COFDM modulation,H.264/H.265 coding

Specifications: :

DC Input	AC220V/DC12V <1A
Working Current	≤1.1A DC12.5V
Receiving sensitivity	≤-102dBm /4MHz, ≤-95dBm /8MHz
BER	BER≤1×10-4
Frequency input range	300MHz~4700MHz
Input interface	N(type),Dual antenna diversity reception technology
Modulation	COFDM
RF bandwidth	4/8MHz (adjustable)
Constellation	QPSK,16QAM,64QAM (optional)
Encryption	AES 128/265 bit / ALLTECH Basic scrambling
FEC	1/2,2/3,3/4,5/6, 7/8 (optional)
Guard Interval	1/32,1/16,1/8,1/4 (optional)
Carrier	2K
Video formats and amplitude	PAL/NTSC, 1Vp-p/75Ω
Video compression	H.264/H.265/MPEG-2(autoadaptation)
Decode code stream rate	0.5-12Mbps
Video output interface	Composite video RCA,HDMI,ASI,HD-SDI(alternative)
Video channel characteristic	Differential gain DG≤1.5%, Differential phase DP≤1°
Audio output	Left and right channel and stereo
Dimension	17014060mm
Weight:	1kg

COFDM Wireless Video Camera Transmitter And Receiver 433mhz 800mhz
